25TAC47BDGG:
"25" typically denotes the bore diameter, which is 25mm in this case.
"TAC" stands for "Thrust Angular Contact."
"47" typically represents the outside diameter, which is 47mm.
"B" signifies that this is a double-direction bearing, which means it can support thrust loads in both directions.
"D" is often used to indicate that it's a contact angle of 60 degrees. This means that the bearing is designed to handle both radial and axial loads, with a focus on axial load capacity.
"GG" may refer to some specific design or tolerance specifications, which can vary between manufacturers. It could indicate precision or special features of the bearing.
25*62*15mm:
These numbers represent the basic dimensions of the bearing:
25mm is the bore diameter.
62mm is the outside diameter.
15mm is the width of the bearing. This indicates the thickness of the bearing in the axial direction.
BSD2562C:
"BSD2562C" appears to be the specific model or part number for this bearing, and it may be the manufacturer's designation. It may also include additional specifications or design features, which are particular to this model.
Ball screw support bearings, like the BSD2562C, are designed for use in precision applications, where accurate linear motion and high axial load capacity are essential. These bearings are commonly used in machinery and equipment that requires precise positioning and movement, such as CNC machines, robotics, and other automated systems.
It's important to note that the specific designations and nomenclature of bearings can vary between manufacturers, so it's always a good practice to consult the manufacturer's documentation for detailed technical specifications and tolerances for a particular bearing model.
